SILICA BOARD & H.T.B

Sep 10 , 2018

Table of Content [Hide]

SILICA BOARD & H.T.B is an insulating materials for heat insulation.
it has outstanding heat-resisting, water-resisting, compression strength and is crashworthy.
So it is light and transformed easily as necessary that it is used in various kinds of fire-proof equipment.
According to crystal structure, Silica' workable temperature is – 650℃ and HTB' is – 1000℃.

Silicon Plate

(mm) Length	(mm) Width	(mm) Thickness
900	600	25,40 50,60 75,100
600	600
600	300
600	150

Silicon Plate

Project		silicon plate	High Temp Silica Board (Super Board) H.T.B	High Strength Super Board high strength H.T.B
Specifications	Max Temp.	650	1000	1000
	Bulk Density	0.22 below	0.22 below	0.35 below
	Bending Strength	3.0 the above	4.0 the above	12.0 the above
	Reheat Change ()	(650) 2.0 below	(1000) 1.5 below	(1000) 1.5 below
	Thermal conductivity	0.053below at±70±5°C	0.075below at350±10°C	0.090below at350±10°C
